CENA3
SpringFit™ 2,5" ceiling speaker
Eye catching complete family
Fastest possible installation time with unique Springfit™ innovation
High intelligibility and sound accuracy
Snapconnect™ enabling a fast and reliable connection

The unbeatable one. The CENA series are full-range ceiling speakers, designed to offer an unmatched solution for large scale public address projects. The SpringFit™ fixation offers the fastest possible installation time of any speaker available on the market, while the borderless grill design is absolutely unseen for any ceiling speaker in this segment. With the selection of high-quality cone materials, exceptional intelligibility and background music performance are guaranteed. The CENA Series are equipped with SnapConnect™, a faster, more reliable and safer choice for fixed installations, accepting solid and stranded wires with sections up to 4.0 mm².

The CENA3 features a 2,5” broadband driver with a continuous power handling of 10 Watt (RMS) and maximum power handling of 20 Watt. It is fitted with a multi-tapping 100V line transformer with tappings for 6W and 3W.

OPTIMAL SPEECH AND BACKGROUND SOUND
High intelligibility and sound accuracy
CENA series are full-range ceiling speakers, designed to offer an unmatched solution for large-scale public-address projects. With a selection of high-quality cone materials, exceptional intelligibility and background music performance are guaranteed.

FASTEST POSSIBLE INSTALLATION TIME
Springfit™ technology
The SpringFit™ installation system allows installation of the CENA series speakers in a snap. Bend the mounting arms inwards and insert the speaker through the provided cut-out. The spring loaded mechanism will flip out and lock the speaker behind the ceiling surface.

A FAST AND CONVENIENT CONNECTION
SnapConnect™ connection
A more user-friendly equivalent for screw terminal connectors to connect speaker cables together. SnapConnect™ is a faster, more reliable and safer choice for fixed installations, accepting solid and stranded wires with sections up to 4.0 mm².

Peak power handling 40 W
Program power handling 20 W
RMS/AES power handling 10 W
Sound Pressure (Max. W/1m) @ 100 V 97 dB
Sensitivity (1W/1m) 87 dB
Speaker type Broadband
Connection SnapConnect™
Impedance 8 ?
Frequency Response (± 3 dB) 120 Hz - 20 kHz
Range (-10 dB) 95 Hz - 20 kHz
Line Transformer Tappings 1 6 W / 1667 ?
2 3 W / 3333 ?
Drivers 2,5” Full Range
Dispersion Conical 160°
Product Features
Construction ABS
Front finish borderless finely perforated steel grill
Mounting SpringFit™ mounting system
Colours White (RAL9003) (CENA306/W)
Black (RAL9005) (CENA306/B)
Cut-out measurement 80 mm (Ø)
Dimensions 95 x 72 mm (Ø x D)
Weight 0.36 kg
Operating temperature -15 °C ~ 55 °C
