Signage Solutions Skjerm i Q-serien
86BDL3650Q/00Skill deg ut fra mengden
Informer og imponer med en digital Philips Q-Line 4K Ultra HD-skjerm. Denne pålitelige, brukervennlige og Android-drevne skiltløsningen er Wave-klar for ekstern administrasjon, noe som gir deg full kontroll, når som helst, hvor som helst.
| Picture/Display |
|
|
|
|
Diagonal screen size
(inch) |
85.6 |
| Diagonal screen size (metric) |
217.4 |
| Panel resolution |
3840 x 2160 |
| Optimum resolution |
3840 x 2160 @ 60 Hz |
| Brightness |
400 |
| Contrast ratio (typical) |
1200:01:00 |
| Dynamic contrast ratio |
500,000:1 |
| Response time (typical) |
8 |
| Aspect ratio |
16:9 |
| Viewing angle (horizontal) |
178 |
| Viewing angle (vertical) |
178 |
| Pixel pitch |
0.4935 x 0.4935 mm |
| Display colours |
1.07 Billion |
| Picture enhancement |
3/2 - 2/2 motion pull down |
| |
Progressive scan |
| |
Dynamic contrast enhancement |
| Panel technology |
IPS |
| Operating system |
Android 10 |
| Haze |
25 % |
|
|
|
|
|
Supported
Display Resolution |
|
|
|
|
Computer formats |
1920
x 1080, 60 Hz |
| |
1680 x 1050, 60 Hz |
| |
1600 x 1200, 60 Hz |
| |
1440 x 900, 60 Hz |
| |
1280 x 1024, 60 Hz |
| |
1280 x 800, 60 Hz |
| |
1280 x 720, 60 Hz |
| |
1024 x 768, 60, 70, 75 Hz |
| |
1152 x 864, 75 Hz |
| |
3840 x 2160, 60 Hz, 50 Hz |
| |
720 x 400, 70 Hz |
| |
800 x 600, 56, 60, 72, 75 Hz |
| |
800 x 600, 56, 60, 72 Hz |
| |
832 x 624, 75 Hz |
| Video formats |
1080i, 50, 60 Hz |
| |
720p, 50,60 Hz |
| |
1080p, 50, 60 Hz |
| |
2160p, 50, 60 Hz |
|
|
|
Connectivity |
|
|
|
|
Video input |
USB
2.0 (x 2) |
| |
DVI-I (x 1) |
| |
HDMI 2.0 (x 2) |
| |
USB 3.0 (x1) |
| Audio input |
3.5 mm jack |
| Audio output |
3.5 mm jack |
| External control |
RS232C (in/out) 2.5 mm jack |
| |
IR (in/out) 3.5 mm jack |
| |
RJ45 |
| Other connections |
micro SD |
| |
OPS |
|
|
|
Convenience |
|
|
|
|
Keyboard control |
Hidden |
| |
Lockable |
| Network controllable |
RS232 |
| |
RJ45 |
| Signal loop through |
RS232 |
| |
IR Loop through |
| Energy-saving functions |
Smart Power |
| Remote control signal |
Lockable |
| Tiled Matrix |
Up to 3 x 3 |
| Placement |
Landscape (18/7) |
| |
Portrait (18/7) |
| Ease of installation |
Smart Insert |
|
|
|
Dimensions |
|
|
|
|
Bezel width |
15.5 mm
(Even bezel) |
| Set Width |
1929.0 |
| Set Height |
1100.0 |
| Set Depth |
69.5 mm(D@wall
mount)/91.8 mm(D@handle) |
| Set Width (inch) |
75.94 |
| Set Height (inch) |
43.31 |
| Set Depth (inch) |
2.74(@ wall mount)/3.61(@ handle) |
| Product weight |
49.06 |
| Product weight (lb) |
108.16 |
| Wall Mount |
600 mm x 400 mm, M8 |
|
|
|
Operating
conditions |
|
|
|
|
Altitude |
0
~ 3000 m |
| Temperature range (operation) |
0 ~ 40 |
| Temperature range (storage) |
-20 ~ 60 |
| MTBF |
50 |
| Humidity range (operation)[RH] |
20~80% RH (No condensation) |
| Humidity range (storage) [RH] |
5~95% RH (No condensation) |
|
|
|
Power |
|
|
|
|
Mains power |
100–240 V~,
50/60 Hz |
| Standby power consumption |
<0.5 W |
| Power Saving Features |
Smart Power |
| Consumption (Max) |
540 W |
| Consumption (Typical) |
320 |
| Energy Label Class |
G |
|
|
|
Sound |
|
|
|
|
Built-in speakers |
2
x 10 W RMS |
|
|
|
Accessories |
|
|
|
|
Included Accessories |
IR
sensor cable (1.8 m) (x 1) |
| |
RS232 daisy-chain cable |
| |
Philips logo (x 1) |
| |
AC Power Cord |
| |
AC Switch Cover |
| |
Cable clip (x2) |
| |
HDMI cable (1.8 m) (x 1) |
| |
Quick start guide |
| |
Remote control and AAA batteries |
| |
RS232 cable |
| |
USB Cover (x 1) |
|
|
|
Multimedia
Applications |
|
|
|
|
USB Playback Video |
H.264 |
| |
H.263 |
| |
H.265 |
| |
MPEG1/2 |
| |
MPEG4 |
| |
VP8 |
| |
VP9 |
| USB Playback Picture |
BMP |
| |
JPEG |
| |
PNG |
| USB Playback Audio |
AAC |
| |
HEAAC |
| |
MPEG |
|
|
|
Miscellaneous |
|
|
|
|
Warranty |
3 year
warranty |
| On-Screen Display Languages |
Simplified Chinese |
| |
Traditional Chinese |
| |
English |
| |
French |
| |
German |
| |
Italian |
| |
Polish |
| |
Russian |
| |
Spanish |
| |
Turkish |
| |
Japanese |
| |
Arabic |
| Regulatory approvals |
CE |
| |
CB |
| |
FCC, Class A |
| |
VCCI |
| |
RoHS |
| |
UL |
|
|
|
Internal
Player |
|
|
|
|
CPU |
Quad
Core Cortex A55 |
| GPU |
G52 MC1 |
| Memory |
16Gb
|
| |
3 GB DDR |
