Blaze Audio PowerZone Connect 1008D UNI
8x125W | 4-8 Ohm | 4x250w | 100V | 16 Ohm
Dante model; Pictures and product information will be updated when available.
The PowerZone Connect 1008 is a compact DSP amplifier in a half rack, 1U format. It’s network-connected, giving wired or wireless access to the PowerZone Control web app’s system setup and audio configuration menu. From here you can manage inputs/outputs, control sound zones and access professional tuning settings – all helping achieve impressive sound in the shortest time possible.
It can drive both conventional low impedance (4O to 16O) loudspeakers and constant voltage (70V/100V) transformer coupled loudspeakers. With four analogue inputs, and one stereo digital input, it has flexible output options – 8 x 125W in Lo-Z mode and 4 x 250W in Hi-Z mode. Automatic power sharing technology enables 250W to be shared proportionately between each pair of Lo-Z outputs.
- Full matrix DSP amplifier with configuration and control via the simple WebApp
- Flexible power output with 8 x 125W / 4 x 250W and power sharing technology
- Route any input to any output channel – create sound Zones in minutes
- Ultra-compact form factor means it can be installed in spaces where others cannot
- Powered by Pascal UMAC™ Class-D technology
Specifications
| Output
Power @ 4/8O |
8
x 125 W |
| Output
Power @ 70/100V* |
4 x 250 W |
| Total
System Power |
1000
W |
| Power
Consumption |
300 W |
| Dimensions |
44
x 440 x 319 mm |
| 1.7 x 17.3 x 12.6 in |
| Weight |
3.8 kg | 8.4
lbs |
Accessories
- 2x Rack ears
- 1x ½ rack plate extension
- 2x ½ rack mounting
- 2x Rear supports
- Power Ratings 1% THD @ 120Vac and 230Vac
